Mbsm.pro, compressor, qp325pba, 2 hp, 1856 w, r22, 20000 btu/h, 1PH, 220-240V, 50Hz , QJ series LG compressor

image_pdfimage_print

More QJ series LG compressor model as follow:

Power Source Model Cooling Capacity Motor Input EER COP c
[Btu/hr] [Watts] [Watts] [Btu/W.hr] [W/W] [cc]
1PH, 220-240V, 50Hz QP325P 19200 19300 5626 5656 1778 1856 10.8 10.4 3.16 3.05 700
QP348P 20500 20600 6007 6037 1884 1967 10.9 10.5 3.19 3.07 700
QP376P 22600 22700 6623 6652 2112 2183 10.7 10.4 3.14 3.05 700
QP390P 23000 23200 6740 6799 2130 2188 10.8 10.6 3.16 3.11 700
QP407P 24050 24300 7048 7121 2227 2314 10.8 10.5 3.16 3.08 700
QP425P 25000 25100 7326 7355 2336 2346 10.7 10.7 3.14 3.14 700
QP442P 26000 26100 7619 7648 2430 2534 10.7 10.3 3.14 3.02 700
QP464P 27600 27700 8088 8117 2654 2885 10.4 9.6 3.05 2.81 700
1PH, 200-220V, 50Hz QP325J 19200 5626 1829 10.5 3.08 700
QP376J 22500 6594 2102 10.7 3.14 700
QP407J 24700 7239 2287 10.8 3.17 700
QP425J 25860 7579 2370 10.9 3.19 700
QP442J 26860 7872 2633 10.2 2.99 700
3PH, 380-420V QP325Y 19200 19400 5626 5685 1778 1796 10.8 10.8 3.16 3.17 700
QP425Y 25000 25400 7326 7443 2380 2419 10.5 10.5 3.08 3.08 700
QP442Y 26000 26300 7619 7707 2430 2500 10.7 10.5 3.14 3.08 700
Power Source Model Cooling Capacity Motor Input EER COP c
[Btu/hr] [Watts] [Watts] [Btu/W.hr] [W/W] [cc]
1PH, 220-240V, 50Hz QP325P 19200 19300 5626 5656 1778 1856 10.8 10.4 3.16 3.05 700
QP348P 20500 20600 6007 6037 1884 1967 10.9 10.5 3.19 3.07 700
QP376P 22600 22700 6623 6652 2112 2183 10.7 10.4 3.14 3.05 700
QP390P 23000 23200 6740 6799 2130 2188 10.8 10.6 3.16 3.11 700
QP407P 24050 24300 7048 7121 2227 2314 10.8 10.5 3.16 3.08 700
QP425P 25000 25100 7326 7355 2336 2346 10.7 10.7 3.14 3.14 700
QP442P 26000 26100 7619 7648 2430 2534 10.7 10.3 3.14 3.02 700
QP464P 27600 27700 8088 8117 2654 2885 10.4 9.6 3.05 2.81 700
1PH, 200-220V, 50Hz QP325J 19200 5626 1829 10.5 3.08 700
QP376J 22500 6594 2102 10.7 3.14 700
QP407J 24700 7239 2287 10.8 3.17 700
QP425J 25860 7579 2370 10.9 3.19 700
QP442J 26860 7872 2633 10.2 2.99 700
3PH, 380-420V QP325Y 19200 19400 5626 5685 1778 1796 10.8 10.8 3.16 3.17 700
QP425Y 25000 25400 7326 7443 2380 2419 10.5 10.5 3.08 3.08 700
QP442Y 26000 26300 7619 7707 2430 2500 10.7 10.5 3.14 3.08 700
