Compressor ACC Cubigel Huayi Electrolux ZEM GL50AA / GVM44AA > new model GLY45AA
Refrigerant:
R134a
Power range(W):
0 – 100 W
Connecting size:
5,9 mm
Suction:
7,5 mm
Working area:
LBP
Design type:
Hermetic
Model series:
GL
Use with:
Capillary
Power range(HP):
0-2
Power supply:
230 V
Temperature range:
-35 to -10
Oil type:
ISO VG 22 Ester
Engine type:
RSIR
Article condition:
New
Info:
Oil filled
Shipping weight:
8,50 kg
Dimensions ( Length × Width × Height ):
20,40 × 16,20 × 17,50 cm
Cooling capacity condition:
-25 / +55 °C
customs tariff number:
84143081
Manufacturer:
ACC Cubigel Huayi Electrolux ZEM
Size:
7.5 + 5.9 mm
Model:
GL50AA
Modelname:
Stroke volume (cm3):
3,38
Cooling capacity (W):
90
Power (HP):
0,15
Max. Starting current (A):
8,1
Max. Operating current (A):
0,72
Engine type:
RSIR
COP:
0,83
Note:
Static cooling
Oil quantity (l):
0,21
Compressor type:
Piston
Alternative:
GLY45AA, TLS5F
Pressure line (mm):
5,9
Suction line (mm):
7,5
