Compressor ,ACC Cubigel ,Huayi ,Electrolux ,ZEM ,GP16TG, HMBP,R134a, 200- 220V / 220-230V/1/50/60Hz, 3/8 HP, displacement 16,15 cm3

image_pdfimage_print

Compressor ACC Cubigel Huayi Electrolux ZEM GP16TG, HMBP – R134a, 200- 220V/220 – 230V/1/50/60Hz, 3/8 HP, discharge 16.15 cm3, motor type CSIR, oil type ISO VG 46 ester, oil charge 400 cm3, 1205 W at +5 / +55 °, input power, current 662 W, 4.28 A, expansion device: capillar or valve, cooling: fan, weight 12.9 kg , the statutory warranty period shall apply (24 months), Delivery time Info: with “immediately available” and “scarce stock”, usually delivery within 2 days. For “currently not available” delivery time usually 2 weeks or delivery time in urgent cases contact us.

Refrigerant:R134a
Power range(W):1 – 1,5 kW
Connecting size:6,5 mm
Suction:8,1 mm
Working area:HMBP
Design type:Hermetic
Model series:GP
Use with:Expansion/Capillary
Power range(HP):0-2
Power supply:230 V
Oil type:ISO VG 22 Ester AB46 ISO VG 46 Ester
Engine type:CSIR
Article condition:New
Info:Oil filled
Shipping weight:24,90 Kg
Dimensions ( length × width × height ):23,10 × 16,20 × 21,10 cm
Cooling capacity condition:+5 / +55 C
Manufacturer:ACC Cubigel Huayi Electrolux ZEM
Model:GP16TG
Stroke volume (cm3):16,15
Cooling capacity (W):1205
Power (HP):0,4
Power consumption (W):662
Max. Starting current (A):23
Max. Operating current (A):4,28
Engine type:CSIR
COP:1,82
Note:Fan cooling necessary
Oil quantity (l):0,4
Compressor type:Piston
Pressure line (mm):6,5
Suction line (mm):8,1
