Compressor ,ACC Cubigel ,Huayi Electrolux ,ZEM GL80AA / GVY75AA, LBP – R134a, 220 – 240V/1/50Hz, 1/4 HP, discharge 7.52 cm3, motor type RSIR / RSCR, oil type ester, oil charge 180 cm3, 150 W at -25 / +55 °, input power, current 146 W, 1.16 A, expansion device: capillary, cooling: static, weight 8.6 kg
| Refrigerant: | R134a |
| Power range(W): | 101 – 200 W |
| Performance range (C): | -35 C to -10 C |
| Connecting size: | 4,9 mm |
| Suction: | 6,5 mm |
| Working area: | LBP |
| Design type: | Hermetic |
| Model series: | GL |
| Use with: | Capillary |
| Power range(HP): | 0-2 |
| Power supply: | 230 V |
| Oil type: | ISO VG 19 Ester |
| Engine type: | RSIR RSCR |
| Article condition: | New |
| Info: | Oil filled |
| Shipping weight: | 9,60 Kg |
| Contents: | 1,00 Pieces |
| Dimensions ( length × width × height ): | 23,10 × 16,20 × 18,60 cm |
| Cooling capacity condition: | T0 -25 C, Tk +55 C |
| Manufacturer: | ACC Cubigel Huayi Electrolux ZEM |
| Model: | GL80AA |
| Modelname: | GVY75AA |
| Stroke volume (cm3): | 7,52 |
| Cooling capacity (W): | 144 |
| Power (HP): | 0,25 |
| Max. Starting current (A): | 11,5 |
| Max. Operating current (A): | 1,16 |
| Engine type: | RSIR / RSCR |
| COP: | 0,88 |
| Note: | Static cooling |
| Conveying and suction volume (m3): | 1,4 |
| Oil quantity (l): | 0,18 |
| Compressor type: | Piston |
| Power range: | -35 C to -10 C |
| Alternative: | NEK1116Z , NB1116Z , GL75AA, NL9F |
| Pressure line (mm): | 4,9 |
| Suction line (mm): | 6,5 |
Danfoss Refrigeration, R134a,GL90TG ,220-240V 50-60Hz, R134A ,HBP ,CSIR ,compressor Haute pression avec condensateur
Type: Hermetic piston compressors
Producer: ACC
Series: HMBP
Model: GL90TG
General data
| Refrigerant: | R134a | |
| Discharge element: | C-V | |
| Cooling: | F | |
| Maximum ambient temperature [ºC]: | 43 |
Compressor’s data
| Cylinder capacity [cm³]: | 8,9 | |
| Displacement [m³/h]: | 1,5 | |
| Weight [kg]: | 10,8 | |
| Oil charge [cm³]: | 300 | |
| Oil type: | ISO VG 22 ESTER |
Engine’s data
| Engine type: | CSIR | |
| Power [KM]: | 1/4 | |
| Starting element: | HST | |
| Power supply: | 200V 50Hz | |
| Voltage range: | 170-242 | |
| Locked rotor current [A]: | 12 | |
| Running winding resistance (25ºC) [Ω]: | 5,91 | |
| Starting winding resistance (25ºC) [Ω]: | 23,35 |
Electrical data
| Relays: | 9660 A 145, MTRP 46 | |
| Shielding element: | MRP36AMK, T0171 | |
| Starting capacitor volume [μF]: |
Connections
| milimeters | inches | ||
| Suction/service tube: | 6,5 | ||
| Service/suction tube: | 6,5 | ||
| Discharge tube: | 4,9 |
Brandt Compresseur, L.B.P ,HVY67AA ,220-240/50,1/7 Hp ,Réfrigérateur Congélateur Indesit, r600 ,107w
Descriptif détaillé
Compresseur HVY67AA 1/7 R600 pour réfrigérateur / congélateur – Ariston Indésit
Ce compresseur HVY67AA 1/7 R600 pour réfrigérateur / congélateur se monte sur les marques et modèles suivants
| Référence technique – référence commerciale |
| Ariston Indésit Hotpoint Scholtes |
| BFS1221HA F064885 |
| BFS1222HA F064884 |
| INFS1211 F064875 |
| INFS1211UK F064874 |
| RZAAV21G.1 F083751 |
| SC09UFRAI F069091 |
| VR120A F065057 |
Références équivalentes
Indésit C00277059 – 277059 – C00283417 – 283417 – C00115821 – 115821
Compressor ,Moteur HP ,CSIR ,Avec Condensateur ,CUBIGEL ,GL80TB ,R-134a 1/5HP ,230V ,HMBP ,High-Medium Back Pressure
Données techniques
- Modèle: GL80TB
- Gaz: R-134a
- Température/Pression: Moyenne / Haute
- Puissance: 1/5 HP
- Voltage: 230 V
- Type De Courant: Monophasé
- Fréquence: 50 Hz
- Type De Compresseur: Hermétique
- Décalage: 7.57 cm³
- Cons.Énergie -25ºC: 150 W
- Cons.Énergie -10ºC: 202 W
- Cons.Énergie -5ºC: 220 W
- Cons.Énergie 0ºC: 238 W
- Cons.Énergie +5ºC: 257 W
- Application Compress: Capillaire/Soupape
- Cons.Énergie +10ºC: 833 W
- T° De Condensation: 40 °C
- Capacidad Frigorífica -25°C: 150 Kcal/h
- Capacidad Frigorífica -20°C: 206 Kcal/h
- Capacidad Frigorífica -15°C: 274 Kcal/h
- Capacidad Frigorífica -10°C: 352 Kcal/h
- Capacidad Frigorífica -5°C: 441 Kcal/h
- Capacidad Frigorífica 0°C: 541 Kcal/h
- Capacidad Frigorífica 5°C: 653 Kcal/h
- Capacidad Frigorífica 7.2°C: 705 Kcal/h
- Capacidad Frigorífica 10°C: 775 Kcal/h
- Tipo Test: Ashare 46
DAEWOO Compressor , HSL25YE-5, 1/5 hp++, 1/4HP– , 1PH, R134a ,220-240V 50Hz,Puissance frigorifique 176 W ,690 BTU
www.mbsm.pro, cOMPRESsOR A/A , R22 ,124MBTU, 220V/380v, 3HP, H25G124DBDE, BRISTOL
www.mbsm.pro, cOMPRESsOR A/A ,124MBTU, 220V/380v, 3HP, H25G124DBDE, BRISTOL
1 RT (Ton) = 12000 BTU/hr
124M BTU/hr = 10 Ton
www.mbsm.pro, Branchement de Contacteur ,De Réponse Carte mère, Climatiseur ,Sharp
www.mbsm.pro, Branchement de Contacteur ,De Réponse Carte mère, Climatiseur ,Sharp
A1 = Entrée Courant de réponse carte mère Neutre (N) Noir 1.5mm2
A2 = Entrée Courant de réponse carte mère Phase (1) Rouge 2.5mm2
A1/a2 = C’est la Bobine 220v 50H
L1 /L3 = Entrée Courant de La Ligne De Curant Direct Phase Rouge 2.5mm2
T1/T3 = Retour Du Compresseur Fil Rouge 2.5mm2
www.mbsm.pro , compressor, R134a ,ff16hak ,170 watt ,1/4 HP ,1PH
www.mbsm.pro , compressor, R134a ,ff16hak ,170 watt ,1/4 HP ,1PH
