Description

Product details

Gross weight 12.47 kg
Net weight 12.47 kg
Gross weight 12.47 kg
Net weight 12.47 kg

Application energy level High Energy-optimized
Applications LBP
Auxiliary winding resistance (start winding) for single-phase compressors alt [Ohm] 31.8 Ohm
Base plate type EU small
Brand technique Reciprocating compressor
Capacity control Fixed speed
Colour Black
Compressor power supply [V/Ph/Hz] 220-240/1/50
Configuration code Single
Cut in current LST [A] 6.4 A
Description NLX11KK.2
Discharge connection angle [°] 21 °
Discharge connection comments Al-cap
Discharge connection diameter [mm] 5 mm
Discharge connection material Cu-plated steel
Economizer No
Free gas volume [cm3] 2360 cm3
Frequency [Hz] 50
Height from baseplate [mm] 197 mm
High value of nominal voltage at 50Hz [V] 240 V
High value of voltage range at 50Hz [V] 255 V
Length [mm] 252 mm
Liquid injection No
Low value of nominal voltage at 50Hz [V] 220 V
Low value of voltage range at 50Hz [V] 187 V
LRA LST [A] 3.5 A
Main winding resistance for single-phase compressors [Ohm] 18.5 Ohm
Model number NLX11KK.2
Motor type RSCR
No. of phases (compressor) 1
Oil quantity [cm3] 270 cm3
Oil type POE
Packing format Industrial pack
Packing quantity 80
Process connection angle [°] 25 °
Process connection comments Al-cap
Process connection diameter [mm] 6.2 mm
Process connection material Cu-plated steel
Refrigerant R600a
Refrigerant charge [kg] [Max] 0.15 kg
RLA 0.70 A
Rotational speed at 50Hz [rpm] 3000 rpm
Run capacitor capacitance 2 µF
Segment usage Refrigeration LT
Speed Platform Fixed-speed
Suction connection angle [°] 2 °
Suction connection comments Al-cap
Suction connection diameter [mm] 6.2 mm
Suction connection material Cu-plated steel
Swept volume [cm3] 11.15 cm3
Technology Reciprocating
Total height [mm] 203 mm
Type NL
Type designation Compressor
Voltage 50Hz [V] 220 V
Voltage 50Hz [V] [Max] 240 V
Width [mm] 166 mm
Winding temperature short term [°C] [Max] 110 °C
Winding temperature stat [°C] [Max] 95 °C
Application energy level High Energy-optimized
Applications LBP
Auxiliary winding resistance (start winding) for single-phase compressors alt [Ohm] 31.8 Ohm
Base plate type EU small
Brand technique Reciprocating compressor
Capacity control Fixed speed
Colour Black
Compressor power supply [V/Ph/Hz] 220-240/1/50
Configuration code Single
Cut in current LST [A] 6.4 A
Description NLX11KK.2
Discharge connection angle [°] 21 °
Discharge connection comments Al-cap
Discharge connection diameter [mm] 5 mm
Discharge connection material Cu-plated steel
Economizer No
Free gas volume [cm3] 2360 cm3
Frequency [Hz] 50
Height from baseplate [mm] 197 mm
High value of nominal voltage at 50Hz [V] 240 V
High value of voltage range at 50Hz [V] 255 V
Length [mm] 252 mm
Liquid injection No
Low value of nominal voltage at 50Hz [V] 220 V
Low value of voltage range at 50Hz [V] 187 V
LRA LST [A] 3.5 A
Main winding resistance for single-phase compressors [Ohm] 18.5 Ohm
Model number NLX11KK.2
Motor type RSCR
No. of phases (compressor) 1
Oil quantity [cm3] 270 cm3
Oil type POE
Packing format Industrial pack
Packing quantity 80
Process connection angle [°] 25 °
Process connection comments Al-cap
Process connection diameter [mm] 6.2 mm
Process connection material Cu-plated steel
Refrigerant R600a
Refrigerant charge [kg] [Max] 0.15 kg
RLA 0.70 A
Rotational speed at 50Hz [rpm] 3000 rpm
Run capacitor capacitance 2 µF
Segment usage Refrigeration LT
Speed Platform Fixed-speed
Suction connection angle [°] 2 °
Suction connection comments Al-cap
Suction connection diameter [mm] 6.2 mm
Suction connection material Cu-plated steel
Swept volume [cm3] 11.15 cm3
Technology Reciprocating
Total height [mm] 203 mm
Type NL
Type designation Compressor
Voltage 50Hz [V] 220 V
Voltage 50Hz [V] [Max] 240 V
Width [mm] 166 mm
Winding temperature short term [°C] [Max] 110 °C
Winding temperature stat [°C] [Max] 95 °C
