COMPRESSOR:MLY90LA
RefrigerantR404A/R507A
Power supply220 – 240V 1~ 50 Hz

Characteristics

  • Cylinder volume9.09 cm³
  • The weight10.3 kg
  • Suction line connection6.5 mm
  • Pressure line connection4.9 mm
  • Power consumption V/Hz/ph200-230V / 50 / 1
  • Starting current11.5 A
  • Oil filling0.40 dm3
  • Application typelow temperature
  • Compressor SeriesL
  • RefrigerantR404A/R507A
  • Maximum operating current3.2 A
Cooling capacity [W]
c  \ t e-40-35-30-25-20-15-10
40180263358465585716860
45160233317414523644777
50141202276363461527595
55121172236311399500612
60101142195260338427529
Operating conditions: CECOMAF
c  – Condensing temperature [ºC]
e  – Boiling point [ºC]
