Type: Hermetic piston compressors
Producer: ACC
Series: HMBP
Model: GL80DA
General data
| Refrigerant: | R134a | |
| Discharge element: | C-V | |
| Cooling: | S | |
| Maximum ambient temperature [ºC]: | 43 |
Compressor’s data
| Cylinder capacity [cm³]: | 8,1 | |
| Displacement [m³/h]: | 1,4 | |
| Weight [kg]: | 9,9 | |
| Oil charge [cm³]: | 345 | |
| Oil type: | ISO VG 19 ESTER |
Engine’s data
| Engine type: | CSIR | |
| Power [KM]: | 1/5 | |
| Starting element: | HST | |
| Power supply: | 220V 50Hz | |
| Voltage range: | 187-246 | |
| Locked rotor current [A]: | 8 | |
| Running winding resistance (25ºC) [Ω]: | 11,83 | |
| Starting winding resistance (25ºC) [Ω]: | 51,49 |
Electrical data
| Relays: | 9660 B 118, MTRP 33 | |
| Shielding element: | MRP61AMK, T0138 | |
| Starting capacitor volume [μF]: |
Connections
| milimeters | inches | ||
| Suction tube: | 6,5 | ||
| Service tube: | 6,5 | ||
| Discharge tube: | 4,9 |
