Compressor TECUMSEH model: CAJ2446Z-FZ
Refigerant R404A / R507 / R449A / R448A / R452A Working range[stC] LBP -40 do -10 Nominal capacity [W] evaporating temperature -10C 2234 Power supply 220V 50Hz Motor type CSR Displacement [cm³] 26,20 Weight [kg] 21,40
Refrigerant: R404A,
R507,
R449A,
R448A,
R452A
Additional information
| Voltage (V) | 230Vac |
|---|---|
| Frequency (hz) | 50 |
| Range | LBP |
| Displacement (cm3) | 26,2 cm³ |
| Cooling capacity (W) | 755W |
| Conditions (°C) | -30 / +45C |
| Refrigerant | R404A, R448A, R449A, R452A |
| Suction line | Rotalock |
| Liquid line | 5/16″ juotettava |
| Height (mm) | 282 |
| Weight (kg) | 23 |
| Sound level (dB) | 62 |
| Oil | POE |
| Compressor type | Hermetic piston compressor |
Tecumseh Compressor – Model CAJ2446Z
Horsepower: 1 HP
Refrigerant: R404A
Voltage/Frequency: 220-240 V/1 P/50 HZ
Original: France
Manufacturer: Tecumseh
Application: compressor for refrigeration, A/C, cold-room, chiller
Accurate temperature control. Highly efficient with low environmental impact. Low sound level for greater comfort. Easy installation and operation.
