Mbsm.pro, Compressor, Tecumseh, AW704ET-094-A4, AWG5522EXN, 2 HP, RECIPROCATING Compressor, 200-208-220-230/60-50/1, R-22, 28000 btu/h

mbsmpro-compressor-tecumseh-aw704et094a4-awg5522exn-2-hp-reciprocating-compressor-20020822023060501-r22-28000-btuh-mbsm-dot-pro
mbsmpro-compressor-tecumseh-aw704et094a4-awg5522exn-2-hp-reciprocating-compressor-20020822023060501-r22-28000-btuh-mbsm-dot-pro

Product Specifications

Performance

ConditionTest Voltage(R) Btu/h(R) kcal/h(R) W(I) W(E) Btu/Wh(E) kcal/WhW/WEVAP TEMPCOND TEMPAMBIENT TEMPRETURN GASLIQUID TEMP
ARI (R-22)230V ~ 60HZ280007056820428709.762.462.867.2°C (45°F)54°C (130°F)35°C (95°F)18.3°C (65°F)46°C (115°F)

General

Evaporating Temp. Range:-23.3°C to 12.8°C (-10°F to 55°F)
Motor Torque:Low Start Torque (LST)
Compressor Cooling:Fan

Mechanical

Weight:62
Weight Unit of Measure:LB
Displacement (cc):48.427
Oil Type:Polyolester
Viscosity (cSt):32
Oil Charge (cc):1141

Electrical

Voltage Range (50 Hz):180-242
Voltage Range (60 Hz):197-254
Locked Rotor Amps (LRA):73
Rated Load Amps (RLA 50 Hz):0
Rated Load Amps (RLA 60 Hz):13
Max. Continuous Current (MCC in Amps):22
Motor Resistance (Ohm) – Main:.88
Motor Resistance (Ohm) – Start:2.1
MotorType:PSC
Overload Type:N/A
Relay Type:N/A
