Mbsm.pro, Compressor, AE 1370, AE1370, 1/5 hp ++, 158 w, 1/4 hp–, lbp, R134a, replaced by HYE69YK, raded Amp 1.5 A

mbsmpro-compressor-ae-1370-ae1370-15-hp--158-w-14-hp-lbp-r134a-replaced-by-hye69yk-raded-amp-15-a-mbsm-dot-pro
mbsmpro-compressor-ae-1370-ae1370-15-hp--158-w-14-hp-lbp-r134a-replaced-by-hye69yk-raded-amp-15-a-mbsm-dot-pro
mbsmpro-compressor-ae-1370-ae1370-15-hp--158-w-14-hp-lbp-r134a-replaced-by-hye69yk-raded-amp-15-a-mbsm-dot-pro
MODEL  1/4 HP
SODA  R134a
  Watt ± 5% 185
 ABILITYKcal/h ± 5% 215.1
  btu/h ± 5% 631.2
 STREAM 0.69
PERFORMANCEENERGY CONSUMPTION 127.6 W
 COP (W / W ± 5%)1.45
 EER (BTU/(Wh)±5%)4.9
 NOISE 45
 OVERLOAD PROTECTOR DRB186P61A2/BT48-125
 BT48-125A61D3
COMPONENTSLAST TRIP CURRENT1.05~1.35A
ELECTRICALOPENING TEMPERATURE125±5℃
 CLOSING TEMPERATURE61±9℃
