Data Sheet
| Power supply | 220/240 V-50 Hz-1 Ph |
|---|---|
| Horsepower | 1/5 hp |
| Displacement | 6,50 cm3 |
| Cooling capacity at ASHRAE LT conditions, R134a | 0,16 kW |
| Refrigerant | R134a |
| Suction pipe | 1/4″ |
| Discharge pipe | 1/4″ |
| Weight | 6,80 kg |
| Rated current | 1,10 A |
| LRA | 12,80 A |
| MCC | 124,00 A |
| Type of oil | Ester |
| Other remarks | Electrical components are included |
| Sound level | 42 dB |
| Application | LBP |
| Technology | Fixed speed |
| Maximum shell bottom temperature | 95 ºC |
| Maximum discharge temperature | 120 ºC |
| Maximum winding temperature | 120 ºC |
| Type of motor cooling | Suction gas |
| Motor type | 1-Ph Induction motor (RSIR) |
| Motor protection type | External |
| Speed | 2920 rpm |
| Vibration | 0,7 m/s2 |
