Mbsm.pro, Compressor, Tecumseh, TAJ4519T, 16157 Btu/h, 1 1/2 hp, 1.5 hp, big++, MHBP, 34.45m3, 380V/50Hz, R22, 3 PH

mbsmpro-compressor-tecumseh-taj4519t-16157-btuh-1-12-hp-15-hp-big-mhbp-3445m3-380v50hz-r22-3-ph-mbsm-dot-pro
mbsmpro-compressor-tecumseh-taj4519t-16157-btuh-1-12-hp-15-hp-big-mhbp-3445m3-380v50hz-r22-3-ph-mbsm-dot-pro

DESCRIPTION 220V

Engine type: 1 1/2 CV , 3 ph

Type of ventilation: Fan

Voltage code: KZ

Displacement: 34.4

Oil type: Mineral

Viscosity: 68

Oil load: 475 ml

Application: HBP

Voltage: 220V3_60HZ

LRA: 38

DESCRIPTION 440V

Engine type: 1 1/2 CV, 3 ph

Type of ventilation: Fan

Voltage code: TZ

Displacement: 34.4

Oil type: Mineral

Viscosity: 68

Oil load: 475 ml

Application: HBP

Voltage: 440V3_60HZ

LRA: 23

Size and Dimensions

Connection Size (Discharge)1/2″ Valve
Connection Size (Suction)5/8″ Valve

R22 Capacity @ -15 Deg C1780 W
R22 Capacity @ -10 Deg C2304 W
R22 Capacity @ -5 Deg C2911 W
R22 Capacity @ 0 Deg C3601 W
R22 Capacity @ 7.2 Deg C4738 W
R22 Capacity @ 15 Deg C6162 W
