Mbsm.pro, Compressor, Cubigel, Huayi, Electrolux, ZEM, Freezer, ML45TB, HMBP, R404A, R507, 220 – 240V/1/50Hz, 1/5 HP, ++ Big, 1/4 Hp –, CSIR

mbsmpro-compressor-cubigel-huayi-electrolux-zem-freezer-ml45tb-hmbp-r404a-r507-220--240v150hz-15-hp--big-14-hp---csir-mbsm-dot-pro
mbsmpro-compressor-cubigel-huayi-electrolux-zem-freezer-ml45tb-hmbp-r404a-r507-220--240v150hz-15-hp--big-14-hp---csir-mbsm-dot-pro

Compressor ACC Cubigel Huayi Electrolux ZEM ML45TB, HMBP – R404A, R507, 220 – 240V/1/50Hz, 1/5 HP, discharge 4.5 cm3, motor type CSIR, oil type ISO VG46 ester, oil charge 300 cm3, 528 W at +5 / +55 °, input power, current 352 W, 2.04A, expansion device: capillar or valve, cooling: fan, weight 10.1 kg

Refrigerant:R507a R404A
Power range(W):501 – 700 W
Performance range (C):+5 C to +55 C
Connecting size:4,9 mm
Suction:6,5 mm
Working area:HMBP
Design type:Hermetic
Model series:ML
Use with:Expansion/Capillary
Power range(HP):0-2
Power supply:230 V
Oil type:ISO VG 46 Ester
Engine type:CSIR
Article condition:New
Info:Oil filled
Shipping weight:12,10 Kg
Dimensions ( length × width × height ):23,10 × 16,20 × 18,60 cm
customs tariff number:84143081
Cooling capacity condition:+5 / +55 C
Manufacturer:ACC Cubigel Huayi Electrolux ZEM
Model:ML45TB
Stroke volume (cm3):4,5
Cooling capacity (W):528
Power (HP):0,25
Max. Starting current (A):9,5
Max. Operating current (A):2,04
Engine type:CSIR
COP:1,49
Note:Fan cooling necessary
Oil quantity (l):0,3
Compressor type:Piston
Power range:+5 / +55
Alternative:NEK6144GK
Pressure line (mm):4,9
Suction line (mm):6,5
