Mbsm.pro, Compressor, Tecumseh, TAH4518A, 1.5 Hp, HBp, R12, 440V 3~ 60Hz 400V 3~ 50Hz, 1684 W, 14048 btu

mbsmpro-compressor-tecumseh-tah4518a-15-hp-hbp-r12-440v-3-60hz-400v-3-50hz-1684-w-14048-btu-mbsm-dot-pro
mbsmpro-compressor-tecumseh-tah4518a-15-hp-hbp-r12-440v-3-60hz-400v-3-50hz-1684-w-14048-btu-mbsm-dot-pro

Product Description

Type:Reciprocating Compressors
Application:HBP – High Back Pressure
ProductDescription:R-12
Voltage/Frequency:440V 3~ 60Hz 400V 3~ 50Hz
Version:N/A

Performance

ConditionTest Voltage(R) Btu/h(R) kcal/h(R) W(I) W(E) Btu/Wh(E) kcal/WhW/WEVAP TEMPCOND TEMPAMBIENT TEMPRETURN GASLIQUID TEMP
EN12900440V 3~ 60HZ165364167484521077.851.982.35°C (41°F)45°C (113°F)32°C (90°F)15°C (59°F)45°C (113°F)
EN12900400V 3~ 50HZ140483540411616778.382.112.455°C (41°F)45°C (113°F)32°C (90°F)15°C (59°F)45°C (113°F)

General

Evaporating Temp. Range:-15°C to 15°C (5°F to 59°F)
Motor Torque:High Start Torque (HST)
Compressor Cooling:Fan

Mechanical

Weight:30
Weight Unit of Measure:KG
Displacement (cc):53.2
Oil Type:Mineral
Viscosity (cSt):68
Oil Charge (cc):1330

Electrical

Voltage Range (50 Hz):340-440
Voltage Range (60 Hz):396-499
Locked Rotor Amps (LRA):25
Rated Load Amps (RLA 50 Hz):3.5
Rated Load Amps (RLA 60 Hz):3.4
Max. Continuous Current (MCC in Amps):5
Motor Resistance (Ohm) – Main:6.3
Motor Resistance (Ohm) – Start:6.3
MotorType:3PH
Overload Type:N/A
Relay Type:N/A
