www.mbsm.pro, Compresseur THG1365YGS, R134a ,1/5HP ,230V ,148W

www.mbsm.pro, Compresseur THG1365YGS, R134a ,1/5HP ,230V ,148W

mbsm-dot-pro-wwwmbsmpro-compresseur-thg1365ygs-r134a-15hp-230v-148w



  • Product Specifications

    Performance

    Refrigeration Capacity Input Power Efficiency EVAP TEMP COND TEMP AMBIENT TEMP RETURN GAS LIQUID TEMP
    Condition Test Voltage Btu/h kcal/h W W Btu/Wh kcal/Wh W/W
    ASHRAE 220V ~ 50HZ 570 144 167 148 3.85 .97 1.13 -23°C (-10°F) 54°C (130°F) 32°C (90°F) 32°C (90°F) 32°C (90°F)
    ASHRAE 220V ~ 60HZ 640 161 188 151 4.24 1.07 1.24 -23°C (-10°F) 54°C (130°F) 32°C (90°F) 32°C (90°F) 32°C (90°F)

    General

    Evaporating Temp. Range:

    -34.4°C to -12.2°C (-30°F to 10°F)

    Motor Torque:

    Low Start Torque (LST)

    Compressor Cooling:

    Static

    Mechanical

    Weight:

    8

    Weight Unit of Measure:

    KG

    Displacement (cc):

    5.9

    Oil Type:

    Polyolester

    Viscosity (cSt):

    10

    Oil Charge (cc):

    243

    Electrical

    Voltage Range (50 Hz):

    180-242

    Voltage Range (60 Hz):

    187-242

    Locked Rotor Amps (LRA):

    12.2

    Rated Load Amps (RLA 50 Hz):

    1.25

    Rated Load Amps (RLA 60 Hz):

    1.07

    Max. Continuous Current (MCC in Amps):

    0

    Motor Resistance (Ohm) – Main:

    10.34

    Motor Resistance (Ohm) – Start:

    31.18

    Motor Type:

    PTCS_IR

    Overload Type:

    N/A

    Relay Type:

    N/A

    Agency Approval

    CE Listed, IRAM Listed, SGS Listed, VDE Listed
