Mbsm.pro, 104L2120, DANFOSS, REFRIGERATION, Reciprocating, compressor, SC18CM, 3/4 hp, lbp, r22, 220v/50hz/1ph

written by Lilianne | 10 March 2024

Refrigerants: R22, Usage segment: Refrigeration LT

Gross weight 13.98 Kg
Net weight 13.98 Kg
Oil AB
Amps locked rotor HST [A] 18.6 To
Applications LBP
Approval standard CE en 60335-2-34 with Annex AA
Auxiliary winding resistance (start winding) for single-phase compressors [Ohm] 14.1 Ohm
Oil quantity [cm3] 600 cm3
Capacity control Fixed speed
Refrigerant charge [kg] [Max] 1.3 kg
Color Black
Cut-in current HST [A] 18.6 To
Configuration code Individual
Description Compressor SC18CM, 240 V
Description SC
Designation Compressor
Packaging format Industrial package
Material of the discharge connection Steel-plated Cu
Material of the process connection Steel-plated Cu
N. º of phases (fan) One
Energy level of the application Compressor LBP standard
Model number SC18CM
Refrigerants R22
Resistance of the primary winding for compressors in single-phase [Ohm] 3.7 Ohm
Run capacitor capacitance 10 µF
Start capacitor capacitance 80 µF
Swept volume [cm3] 17.69 cm3
Technology Alternative
Temperature of the winding, the short-term [°C] [Max] 140 °C
Winding temperature, stable [°C] [Max] 130 °C
Voltage, 50 Hz [V] 220 V
Voltage, 50 Hz [V] [max.] 220 V
Engine type CSR
Type of motherboard Universal
Technique of the brand Compressor alternative
Units of packing Eighty
Use of segment Refrigeration LT
Volume of free gas [cm3] 1510 cm3
Mbsm_dot_pro_private_PDF__SC18CMTélécharger
Mbsm_dot_pro_private_PDF_SC18CMTélécharger


Mbsm.pro, compressor, d57c13rax5, 1/6 hp, r134a, Panasonic, Reciprocating, DxxCxxRAW5 series,

written by Lilianne | 10 March 2024
number  Model        HP K Cal/hr BTU/HR W (cooling) displacement cm3
1 D51C10RAW5 1/6 116 461 135 5.1
2 D51C90RAW5 1/6 116 461 135 5.1
3 D57C10RAW5 1/6 121 481 141 5.7
4 D57C13RAX5 1/6 121 481 141 5.7
5 D66C10RAW5 1/5 138 546 160 6.6
6 D66C10RAX5 1/5 130 515 151 6.6
7 D77C10RAW5 1/5   160 635 186 7.7
8 D77C10RAX5 1/5     160 635 186 7.7
9 D91C10RAW5 1/4 195 774 227 9.1
10 D91C10RAX5 1/4 195 774 227 9.1
11 D51C21RAX5 1/3 256 1017 298 11.0
12 D110C21RA25 1/3 256 1017 298 11.0
13 D110C21RBX5 1/3 256 1017 298 11.0
14 D110C24GAX5 1/3 256 1017 298 11.0

Freon type: 134a

Operating voltage: 220-240 volts, 50 Hz

Application type: LBP low pressure

Mbsm_dot_pro_private_PDF_panasonic-compressor-Serie-D-1



Mbsm.pro, compressor, Panasonic, 1/3 hp, Lbp, E Series, R134a, ETI57C13DCH, ENI68C13DCH, Reciprocating, Compressors, Variable Speed, inverter, BLCD, from 63 to 240 w, 240v+-, from 60 to 268 hz, from 25 rps to 72 rps

written by Jamila | 10 March 2024
Specification
Mbsm.pro, compressor, Panasonic, Lbp, E Series, R134a, ETI57C13DCH, ENI68C13DCH, Reciprocating, Compressors, Variable Speed, inverter, from 63 to 240 w, 240v+-, from 60 to 268 hz, from 25 rps to 72 rps
Mbsm_dot_pro_private_PDF_ENI68C13DCH
Item Performance characteristics
Refrigerant R134a
Displacement (cm³) 6.8
Voltage (V) 100
Frequency (Hz) 50
Speed (s⁻¹) 25
Capacity@ASHRAE –
COP@ASHRAE –
Capacity@PREF 78
COP@PREF 1.70


Mbsm.pro, Danfoss, Reciprocating, compressor, NLX11KK.2, 105H6971, NLX11KK.2 105H6971, 1/4 hp++, 1/3 hp–, r600a

written by mahdi miled | 10 March 2024

Description

Product details

Gross weight 12.47 kg
Net weight 12.47 kg
Gross weight 12.47 kg
Net weight 12.47 kg

Application energy level High Energy-optimized
Applications LBP
Auxiliary winding resistance (start winding) for single-phase compressors alt [Ohm] 31.8 Ohm
Base plate type EU small
Brand technique Reciprocating compressor
Capacity control Fixed speed
Colour Black
Compressor power supply [V/Ph/Hz] 220-240/1/50
Configuration code Single
Cut in current LST [A] 6.4 A
Description NLX11KK.2
Discharge connection angle [°] 21 °
Discharge connection comments Al-cap
Discharge connection diameter [mm] 5 mm
Discharge connection material Cu-plated steel
Economizer No
Free gas volume [cm3] 2360 cm3
Frequency [Hz] 50
Height from baseplate [mm] 197 mm
High value of nominal voltage at 50Hz [V] 240 V
High value of voltage range at 50Hz [V] 255 V
Length [mm] 252 mm
Liquid injection No
Low value of nominal voltage at 50Hz [V] 220 V
Low value of voltage range at 50Hz [V] 187 V
LRA LST [A] 3.5 A
Main winding resistance for single-phase compressors [Ohm] 18.5 Ohm
Model number NLX11KK.2
Motor type RSCR
No. of phases (compressor) 1
Oil quantity [cm3] 270 cm3
Oil type POE
Packing format Industrial pack
Packing quantity 80
Process connection angle [°] 25 °
Process connection comments Al-cap
Process connection diameter [mm] 6.2 mm
Process connection material Cu-plated steel
Refrigerant R600a
Refrigerant charge [kg] [Max] 0.15 kg
RLA 0.70 A
Rotational speed at 50Hz [rpm] 3000 rpm
Run capacitor capacitance 2 µF
Segment usage Refrigeration LT
Speed Platform Fixed-speed
Suction connection angle [°] 2 °
Suction connection comments Al-cap
Suction connection diameter [mm] 6.2 mm
Suction connection material Cu-plated steel
Swept volume [cm3] 11.15 cm3
Technology Reciprocating
Total height [mm] 203 mm
Type NL
Type designation Compressor
Voltage 50Hz [V] 220 V
Voltage 50Hz [V] [Max] 240 V
Width [mm] 166 mm
Winding temperature short term [°C] [Max] 110 °C
Winding temperature stat [°C] [Max] 95 °C
Application energy level High Energy-optimized
Applications LBP
Auxiliary winding resistance (start winding) for single-phase compressors alt [Ohm] 31.8 Ohm
Base plate type EU small
Brand technique Reciprocating compressor
Capacity control Fixed speed
Colour Black
Compressor power supply [V/Ph/Hz] 220-240/1/50
Configuration code Single
Cut in current LST [A] 6.4 A
Description NLX11KK.2
Discharge connection angle [°] 21 °
Discharge connection comments Al-cap
Discharge connection diameter [mm] 5 mm
Discharge connection material Cu-plated steel
Economizer No
Free gas volume [cm3] 2360 cm3
Frequency [Hz] 50
Height from baseplate [mm] 197 mm
High value of nominal voltage at 50Hz [V] 240 V
High value of voltage range at 50Hz [V] 255 V
Length [mm] 252 mm
Liquid injection No
Low value of nominal voltage at 50Hz [V] 220 V
Low value of voltage range at 50Hz [V] 187 V
LRA LST [A] 3.5 A
Main winding resistance for single-phase compressors [Ohm] 18.5 Ohm
Model number NLX11KK.2
Motor type RSCR
No. of phases (compressor) 1
Oil quantity [cm3] 270 cm3
Oil type POE
Packing format Industrial pack
Packing quantity 80
Process connection angle [°] 25 °
Process connection comments Al-cap
Process connection diameter [mm] 6.2 mm
Process connection material Cu-plated steel
Refrigerant R600a
Refrigerant charge [kg] [Max] 0.15 kg
RLA 0.70 A
Rotational speed at 50Hz [rpm] 3000 rpm
Run capacitor capacitance 2 µF
Segment usage Refrigeration LT
Speed Platform Fixed-speed
Suction connection angle [°] 2 °
Suction connection comments Al-cap
Suction connection diameter [mm] 6.2 mm
Suction connection material Cu-plated steel
Swept volume [cm3] 11.15 cm3
Technology Reciprocating
Total height [mm] 203 mm
Type NL
Type designation Compressor
Voltage 50Hz [V] 220 V
Voltage 50Hz [V] [Max] 240 V
Width [mm] 166 mm
Winding temperature short term [°C] [Max] 110 °C
Winding temperature stat [°C] [Max] 95 °C

Refrigerant: R600a, Segment usage: Refrigeration LT, Compressor power supply [V/Ph/Hz]: 220-240/1/50Mbsm_dot_pro_private_PDF_nlx11kk.2



Mbsm.pro, Malaysian, Panasonic, reciprocating, compressor, QBxxxxxGAX5 series, QB86C18GAX5, 1/3h, lbp, 222 w, r134a

written by Jamila | 10 March 2024
QB86C18GAX5

R134a QB Series PANASONIC Air Conditioner Compressor ,ALL Application & Refrigerant LBP R134a

general data

Operating voltage: 220V 50Hz

Freon type: 134a

Application type: LBP (low heat)

Piston Engine Type: (RSIR) Resistive Start Induction Run

xx in the piston code number indicates piston displacement



Performance and operation data in a temperature range from -15 to -30 and cooling capacity in watts

      Model  displacement cc -30 -25 -23.3 -20 -15th Oil volume cm3
  QB66C13GAX5 6.55 108 149 165 200 263  …./250
  QB73C15GAX5 7.27 121 167 185 224 294 250/300
  QB77C16GAX5 7.69 131 182 202 245 319 250/300
  QB86C18GAX5 8.56 145 200 222 268 347 250/300
154 213 236 285 372 250/300
QB110C25GAX5 10.86 176 246 273 331 432 250/300

NB

1- The volume of oil needed for the piston increases from 250 to 300 in the case of static condenser (cooling air).

2- The cooling capacity in the table under the following conditions:

Condensing temperature = 54.4 Celsius

Outside temperature = 32.2 Celsius

Sub-cooling temperature = 32.2 Celsius

QB86C18GAX5

QB86C18GAX5



Mbsm_dot_pro_private_PDF_QB86C18GAX5





Mbsm.pro, Copeland, Reciprocating, Hermetic, Compressors, CRNQ-0500-TFD, 5 hp, R22, HCFC, R-22, 50 Hz, 3 – Phase, 380/420 V , CR QR Series

written by Lilianne | 10 March 2024

CRNQ-0500-TFD-522 Copeland Reciprocating Hermetic Compressor for Air Conditioning

Specifications

Model:          CRNQ-0500-TFD-522

Horse power:    5Hp

Refrigerant:    R22

Voltage:        380/420V

Frequency:      50HZ

Phase:          3
Cooling capacity:  51200Btu/hr

power:          5000W

Weight:         82Kgs

Dimension:      286*235*406mm

Style:          hermetic piston

MModel Nominal Power(HP) Capacity(W) Input(KW) Curent(A) Weight (KG) Height (CM)
CRISKQ-TFD-240BN 15 42,50 151 57 272 358
CR24KQ-TFD-240BN 2 56,50 203 59 286 350
CR33KQ-TFD-267RM 2.5 78,50 276 78 304 363
CR37KQ-TFD-240BN 3 91,70 313 94 318 376
CR47KQ-TFD-280BM 4 113,00 381 15 336 388
CRS3KQ-TFD-267RM 45 124,00 43 12 336 388
CR53KQ-TFD-556 45 124,00 43 12 336 388
CRPQ-0450-TFD-522 45 134,00 456 146 38.1 428
CRNQ-0500-TFD-522 5 150,00 5.02 134 38.1 409
QRSOK1-TFD-522 75 217,00 758 221 67.6 468
QRTIMI-TFD-501 9 26100 91 256 67.8 468
QR12M1-TFD-522 10 282,00 101 295 69.4 468
QRI5M1-TFD-501 12 349,00 129 386 726 468odel Nominal Power(HP) Capacity(W) Input(KW) Curent(A) Weight (KG) Height (CM)
CRISKQ-TFD-240BN 15 42,50 151 57 272 358
CR24KQ-TFD-240BN 2 56,50 203 59 286 350
CR33KQ-TFD-267RM 2.5 78,50 276 78 304 363
CR37KQ-TFD-240BN 3 91,70 313 94 318 376
CR47KQ-TFD-280BM 4 113,00 381 15 336 388
CRS3KQ-TFD-267RM 45 124,00 43 12 336 388
CR53KQ-TFD-556 45 124,00 43 12 336 388
CRPQ-0450-TFD-522 45 134,00 456 146 38.1 428
CRNQ-0500-TFD-522 5 150,00 5.02 134 38.1 409
QRSOK1-TFD-522 75 217,00 758 221 67.6 468
QRTIMI-TFD-501 9 26100 91 256 67.8 468
QR12M1-TFD-522 10 282,00 101 295 69.4 468
QRI5M1-TFD-501 12 349,00 129 386 726 468

Mbsm_dot_pro_private_PDF__CRNQ-0500-TFDTélécharger
Mbsm_dot_pro_private_PDF_CRNQ-0500-TFDTélécharger


Mbsm.pro, Compressor, h24b19qabja, Bristol, reciprocating, HERMETIC, Compressor, H2NG, H2BG, H7NG, SELLER Malaysia, 2 Hp, 19000 Btu, 1.5 Ton, R22, 220 v 1 ph

written by Lilianne | 10 March 2024

BRISTOL 2.5HP/1PH H23B24QABKA COMPRESSOR BRISTOL 2.5HP H29B26UABHA COMPRESSOR BRISTOL 2.5HP/1PH H29B30UABHA COMPRESSOR BRISTOL 3.2HP/1PH H23A383ABKA COMPRESSOR BRISTOL 4.0HP/3PH H23A46QDBEA COMPRESSOR BRISTOL 4.0HP/3PH H23A463DBEA COMPRESSOR BRISTOL 3.5HP/3PH H23A56QDBEA COMPRESSOR BRISTOL 5.0HP/3PH H23A56QDBEA COMPRESSOR BRISTOL 5.0HP/3PH H23A62QDBEA COMPRESSOR BRISTOL 5.0HP/3PH H23A623DBEA COMPRESSOR BRISTOL 5.0HP/3PH H29A623DBVA COMPRESSOR BRISTOL 6.0HP/3PH H23A72QDBEA COMPRESSOR Bristol Compressor H29A723DBVA BRISTOL 8.0HP/3PH H2BG094DBEE COMPRESSOR BRISTOL 10.0HP/3PH H2BG124DBEE COMPRESSOR BRISTOL 10.0HP/3PH/380-415V H7BG104DBEE COMPRESSOR BRISTOL 12.5HP3PH H25G144DBEE COMPRESSOR BRISTOL 12HP/3PH H2NG144DREF COMPRESSOR BRISTOL 15HP/3PH H2NG184DREF COMPRESSOR BRISTOL 18HP/3PH H2NG204DREF COMPRESSOR BRISTOL 20HP/3PH H2NG244DREF COMPRESSOR BRISTOL 25HP/3PH H2NG294DPEF COMPRESSOR BRISTOL 25HP/3PH H7NG294DPEF COMPRESSOR BRISTOL 3HP/3PH H73A383DBEA COMPRESSOR BRISTOL 4.0HP/3PH H23A463DBEA COMPRESSOR BRISTOL 25HP/3PH H7NG294DPEF COMPRESSOR BRISTOL MOTOR PROTECTOR P/N 31AA1606E BRISTOL CRANKCASE HEATER 70W X 240V FOR 094, 124 & 144 BRISTOL COMPRESSORS BRISTOL CRANKCASE HEATER 240V FOR H2NG294 BRISTOL COMPRESSORS BRISTOL 8.0HP/3PH H2BG094DBEE COMPRESSOR BRISTOL 10.0HP/3PH H2BG124DBEE COMPRESSOR Bristol Hermetic Reciprocating Compressor H23B24QABKA – (2.5HP/1PH) Bristol Hermetic Reciprocating Compressor H29B26UABHA – (2.5HP/1PH) Bristol Hermetic Reciprocating Compressor H29B30UABHA – (2.5HP/1PH) Bristol Hermetic Reciprocating Compressor H23A383ABKA – (3.0HP/1PH) ; H23B35QABKA & H23A38QABKA Bristol Hermetic Reciprocating Compressor H23A463DBEA – (4.0HP/3PH) ; H23A46QDBEA Bristol Hermetic Reciprocating Compressor H23A56QDBEA – (5.0HP/3PH) ; Bristol Hermetic Reciprocating Compressor H23A623DBEA – (5.0HP/3PH) ; H23A62QDBEA Bristol Hermetic Reciprocating Compressor H29A623DBVA – (5.0HP/3PH) ; H23A623DBEA & 62Q Bristol Hermetic Reciprocating Compressor H29A723DBVA – (6.0HP/3PH) ; H23A72QDBEA Bristol Hermetic Reciprocating Compressor H2BG094DBEE – (8.0HP/3PH) Bristol Hermetic Reciprocating Compressor H2BG124DBEE – (10.0HP/3PH) Bristol Hermetic Reciprocating Compressor H7BG104DBEE – (10.0HP/3PH) Bristol Hermetic Reciprocating Compressor H25G144DBEE – (12.5HP/3PH) Bristol Hermetic Reciprocating Compressor H2NG144DREF – (12.5HP/3PH) Bristol Hermetic Reciprocating Compressor H2NG184DREF – (15.0HP/3PH) Bristol Hermetic Reciprocating Compressor H2NG204DREF – (18.0HP/3PH) Bristol Hermetic Reciprocating Compressor H2NG244DREF – (20.0HP/3PH) Bristol Hermetic Reciprocating Compressor H2NG294DPEF – (25.0HP/3PH) MODEL (R134 , R407 , R404) : Bristol Hermetic Reciprocating Compressor H73A383DBEA – (3.0HP/3PH) R134 & R407 & R404 Bristol Hermetic Reciprocating Compressor H7BG104DBEE – (10.0HP/3PH) R134 & R407 & R404 Bristol Hermetic Reciprocating Compressor H92G244DREF – (20.0HP/3PH) R134 & R407 & R404 Bristol Hermetic Reciprocating Compressor H7NG294DPEF – (25.0HP/3PH) R134 & R407 & R404 ACCESSORIES : BRISTOL MOTOR PROTECTOR P/N 31AA1606E Crank Case Heater (CC Heater) Bristol Hermetic Reciprocating Compressor Crankcase Heater 70W X 240V (094, 124, 144) ZEROL 150 (AB) Or Emkarate RL32H (POE)

Mbsm_dot_pro_private_PDF_h24b19qabjaTélécharger


Panasonic, DGH73C14RAX, R134a, D Series, Reciprocating, Fixed, Speed, LBP, 1/4Hp

written by Lilianne | 10 March 2024

https://www.mbsm.pro/wp-content/uploads/2021/01/Mbsm_dot_pro_private_PDF_Qb77c16glx5.pdf

Item Performance characteristics
Refrigerant R134a
Displacement (cm³) 7.3
Voltage (V) 220
Frequency (Hz) 50
Motor Type RSCR
Capacity@ASHRAE 215
COP@ASHRAE 1.6
Capacity@CECOMAF –
COP@CECOMAF
Mbsm_dot_pro_private_PDF_panasonic-compressor-Serie-DTélécharger


Whirlpool, Aspera, NE2125E, LBP, capacitive, start inductive run, hermetic compressor, R22, 1/4Hp++ or 1/3Hp–

written by Lilianne | 10 March 2024

ompressor Aspera NE2125E, LBP – R22, 220-240V / 1 / 50Hz, stroke volume 8.78 cm3, LRA 11.0A, motor type CSIR, capillary tube / expansion valve operation, oil AB 46.Cooling
capacity measured for condensation temperature of: 45 ° C, Measurement conditions: ASHRAE

Unfortunately the compressor is no longer available.
If you would like an offer for an identical alternative, please email us or give us a short call, we will prepare an offer for you.Cooling capacity (W) at To

– 10 ° C – 15 ° C – 20 ° C – 25 ° C – 30 ° C
651 517 401 304 226
Mbsm_dot_pro_private_PDF_ne2125e-Embraco_VerdichterTélécharger
Shipping Class Default
Scope Of Application LBP
Delivery Time 2-3 Weeks
Stock Availability In Stock
Type Reciprocating Piston
Condensation Temperature 45 ° C
Manufacturer Aspera
Manufacturer No. NE2125E
Power In Hp 1/4 +
Starting Torque HST
Stroke Volume In Cm3 8.78
Measurement Conditions Ashrae
Refrigerant R22
Oil Type ISO46
Series NE
Condensing Units Compressors Compressor
Tension 220-240V
Weight In Kg 10.4



Danfoss, Compressor, 5 Hp, R22, Démontage, ouverture, DESTRUCTION

written by Lilianne | 10 March 2024
danfoss-reciprocating-compressors-mt--mtz--ntz-mt64hm4dve-r22-5hp--hp-39kw--15a-mbsm-dot-pro

danfoss-reciprocating-compressors-mt--mtz--ntz-mt64hm4dve-r22-5hp--hp-39kw--15a-mbsm-dot-pro

danfoss-reciprocating-compressors-mt--mtz--ntz-mt64hm4dve-r22-5hp--hp-39kw--15a-mbsm-dot-pro

danfoss-reciprocating-compressors-mt--mtz--ntz-mt64hm4dve-r22-5hp--hp-39kw--15a-mbsm-dot-pro
