Mbsm.pro, Refrigerator, Alaska, R12, 1998, kgt320, 320 L, Compressor, 1/5 hp, Lbp, r134, 190 g
Mbsm.pro, COMPRESSOR, TECUMSEH, AEA4440YES, AE4440YS, AE630, 1/3+ HP, 220V, 1ph, R134, hbp
Tecumseh/Taikang piston compression AEA4440YES/AE4440YS detailed parameters:
product description
| Product number | product type | application | refrigerant | Mains voltage/frequency | Version |
| AEA4440YES (AE4440YS) | Piston | HBP – High Back Pressure | R-134a | 220V~60Hz | N/A |
Performance/Performance
| condition | Test voltage | Cooling capacity | input power | efficiency | Evaporation temperature | condensation temperature | ambient temperature | Return air temperature | liquid temperature | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Btu/h | kcal/h | W | W | Btu/Wh | kcal/Wh | W/W | |||||||
| ASHRAE | 220V ~ 60HZ | 4200 | 1058 | 1231 | 632 | 6.65 | 1.67 | 1.95 | 7.2°C (45°F) | 54°C (130°F) | 35°C (95°F) | 35°C (95°F) | 46°C (115°F) |
General/General
| Evaporation temperature range: | -6.7°C to 12.8°C (20°F to 55°F) |
| Motor torque: | High Start Torque (HST) |
| Compressor cooling: | fan |
Mechanical/mechanical properties
| weight: | 11 |
| Weight unit: | KG |
| Displacement (cc): | 12.04 |
| Oil type: | N/A |
| Viscosity (cSt): | N/A |
| Oil volume (cc): | 0 |
Electrical/electricity
| Voltage range (50 Hz): | N/A |
| Voltage range (60 Hz): | 187-242 |
| Locked Rotor Ampere (LRA): | 18 |
| Rated load current (RLA 50 Hz): | 0 |
| Rated load current (RLA 60 Hz): | 3.93 |
| Maximum Continuous Current (MCC in Amps): | 0 |
| Motor resistance (ohms) – Mainly: | 4.58 |
| Motor resistance (ohms) – starting: | 18.82 |
| Motor type: | CSIR |
| Overload type: | N/A |
| Relay type: | N/A |
Agency Approval/Agency Approval
Commercial refrigerator, compressors, GLY16RG, 3/8 hp++, R134a, HMBP, 1492W, r134, Compressor ACC, Cubigel, Huayi, Electrolux, ZEM
RT 1320 windsor, windsor refrigerator, 13.2 Feet/cub, 400 L, Compressor, Embraco, ecu75hlp, 250 w, 1/4 hp, Lbp, r134, 180 g, 7.5 cm³, 220-240 V at 50 Hz
The Windsor 1320 refrigerator is a compact 13.2 cubic foot top freezer refrigerator manufactured by Whirlpool. It is available in white, black and silver. The refrigerator has a capacity of 9.7 cubic feet for the refrigerator and 3.5 cubic feet for the freezer. It includes a built-in water and ice dispenser. Opens in a new window www.zillow.com Windsor 1320 Refrigerator Here are some features of the Windsor 1320 refrigerator: 9.7 cubic feet capacity for the refrigerator and 3.5 cubic feet for the freezer Integrated water and ice dispenser LED lighting Touch controls Reversible doors Energy rating F The Windsor 1320 refrigerator is a good choice for people looking for a compact and affordable refrigerator. It comes with all the essential features and offers good performance.
Mbsm.pro, Compressor, ELECTROLUX, ACC, GL60AA, GVY57AA, 1/6 hp, r134
Mbsm.pro, Compresseur, Secop, GTK70AT, 204W, R134, LBP, 1/4 HP, RSIR, 699 BTU
Mbsm.info, Compresseur, Secop, GTK70AT, 204W, R134, LBP, 1/4 HP, RSIR, 699 BTU
Technical Features
| BRAND | SECOP |
| COMPRESSOR TYPE | HERMETIC RECIPROCATING |
| APPLICATION | LBP (-23,3°C / +54,4°C) |
| POWER SUPPLY | 200-240V/50HZ 1~ |
| REFRIGERANT | R134A |
| FREQUENCY (HZ) | 50 |
| OIL TYPE | POLYOLESTER |
| OIL VISCOSITY | 15CST |
| OIL QUANTITY | 156CM³ / 5,3FL.OZ |
| FREE GAS VOLUME COMP. | 1560CM³ / 52,7FL.OZ |
| WEIGHT | 8,6KG / 19LBS |
| MOTOR PROTECTION | EXTERNAL |
| WINDING RESISTANCE MAIN | 11,9Ω (AT 25°C) |
| WINDING RESISTANCE AUX | 11,8Ω (AT 25°C) |
| MAX. WINDING TEMP. | 130°C / 266°F |
| MAX. DISCHARGE TEMP. 1 | 130°C / 266°F |
| DISPLACEMENT | 6,64CM³ / 0,41CU.IN |
| COMPRESSORS ON PALLET | 100 |
Compresor LG 1/6HP MA53LAUG r134
Mbsm.pro, Compresor, LG, 1/6HP, MA53LAUG, r134, lbn
| LG Hermetic Compressor (Refrigerant:R134a)LBP | ||||||||||
| Part No. | Displ. | Motor | Cooling | Capacity | Kcal/Hr | Btu/h | Input power | COP | Power | Weight |
| (cm3) | Type | Type | (W)-23.3? | (w) | W/W | Supply | (kg) | |||
| NS24LAEG | 2.4 | RSIR | ST | 44 | 38 | 150 | 76 | 0.58 | 220-240V/50Hz | 5.8 |
| NS24LBEG | 2.4 | RSIR | ST | 42 | 36 | 143 | 64 | 0.66 | 220-240V/50Hz | 6.4 |
| NS30LAEG | 3.0 | RSIR | ST | 63 | 54 | 214 | 84 | 0.75 | 220-240V/50Hz | 6.4 |
| NS36LAEG | 3.6 | RSIR | ST | 77 | 66 | 261 | 89 | 0.87 | 220-240V/50Hz | 6.4 |
| MSA43LBEG | 4.3 | RSIR | ST | 116 | 100 | 396 | 106 | 1.09 | 220-240V/50Hz | 6.3 |
| MSA43LBEM | 4.3 | RSCR | ST | 116 | 100 | 396 | 97 | 1.20 | 220-240V/50Hz | 6.3 |
| MSA53LAEG | 5.3 | RSIR | ST | 143 | 120 | 478 | 117 | 1.22 | 220-240V/50Hz | 6.3 |
| MSA53LAEM | 5.3 | RSCR | ST | 143 | 120 | 478 | 105 | 1.36 | 220-240V/50Hz | 6.3 |
| MSA53LBEG | 5.3 | RSIR | ST | 143 | 120 | 478 | 130 | 1.10 | 220-240V/50Hz | 6.3 |
| MSA53LBEM | 5.3 | RSIR | ST | 143 | 120 | 478 | 119 | 1.20 | 220-240V/50Hz | 6.3 |
| MSA53LCEG | 4.23 | RSIR | ST | 153 | 103 | 409 | 124 | 1.23 | 220-240V/50Hz | 6.3 |
| MSA63LDEG | 4.23 | RSIR | ST | 153 | 103 | 409 | 124 | 1.23 | 220-240V/50Hz | 6.6 |
| MA53LAEG | 5.3 | RSIR | ST | 142 | 122 | 484 | 106 | 1.34 | 220-240V/50Hz | 8.4 |
| MA53LAEM | 5.3 | RSCR | ST | 142 | 122 | 484 | 99 | 1.43 | 220-240V/50Hz | 8.4 |
| MSA53LCEM | 5.3 | RSIR | ST | 140 | 120 | 478 | 124 | 1.13 | 220-240V/50Hz | 6.3 |
| MA57LAEG | 5.7 | RSIR | ST | 160 | 138 | 548 | 119 | 1.34 | 220-240V/50Hz | 8.6 |
| MA57LAEM | 5.7 | RSCR | ST | 160 | 138 | 548 | 110 | 1.45 | 220-240V/50Hz | 8.6 |
| MA62LCEG | 6.2 | RSIR | ST | 174 | 150 | 596 | 127 | 1.37 | 220-240V/50Hz | 8.8 |
| MA62LCEM | 6.2 | RSIR | ST | 174 | 150 | 596 | 119 | 1.46 | 220-240V/50Hz | 8.9 |
| MA69LCEG | 6.9 | RSIR | ST | 200 | 172 | 683 | 142 | 1.41 | 220-240V/50Hz | 9.3 |
| MA69LCEM | 6.9 | RSCR | ST | 200 | 172 | 683 | 131 | 1.53 | 220-240V/50Hz | 9 |
| MA98LAEM | 9.8 | RSCR | ST | 279 | 240 | 953 | 183 | 1.52 | 220-240V/50Hz | 9.5 |
Samsung SR-40RMB Refrigerator compressor sk170h-l1u 1/4 hp
Mbsm.pro, Samsung, SR-40RMB, Refrigerator, compressor, sk170h-l1u, 1/4 hp, r134, lbp, 195 w
