DESCRIPTION

MX18FB Cubigel ACC hermetic compressor

• 230V-50 Hz.
• LBP.
• power: 5/8 HP.
• height: 221 mm.
• suction connection: 3/8 “.
• connection press: 5/16 “.
• displacement cm³: 18.40.
• gas type: R404A/R507.
• SA = soldering connection
• With the most extended models and 3 levels of efficiency – Standard, High and Very High – using the optional run capacitor concept.
• The Cubigel range offers a solution for all cooling applications.
• The P models are High back pressure compressors for R404A
• Like refrigerators, freezers, bottle coolers, can coolers, ice cream freezers, vending machines, beer dispensers, soft drink dispensers and ice makers.
• The most complete range of Cubigel compressors and Cubigel condensing units for every type of commercial application.
• Cubigel is part of Huayi Compressor Co. Ltd. group in Barcelona, and specializes in designing, manufacturing and selling hermetic compressors and condensing units for the light commercial refrigeration market.
• The Cubigel company focuses on a product innovation strategy based on a strong R&D team, enhanced know-how and more than 50 years of experience providing a broad range of solutions to the commercial refrigeration industry.

Mbsm_dot_pro_private_PDF_GL99AA-compresseur-acc-cubigell-gl99aaTélécharger
Mbsm_dot_pro_private_PDF_GL99AATélécharger

Compressor ACC Cubigel Huayi Electrolux ZEM GL99AA, LBP – R134a, 220-240V/1/50Hz, 1/4 HP, discharge 9.93 cm3, motor type RSIR, LRA 14.4A, expansion device: capillary, cooling: static,weight 11 kg , the statutory warranty period shall apply (24 months), Delivery time Info: with “immediately available” and “scarce stock”, usually delivery within 2 days. For “currently not available” delivery time usually 2 weeks or delivery time in urgent cases contact us.

---

Refrigerant:	R134a
Power range(W):	101 – 200 W
Performance range (C):	-35 C to -10 C
Connecting size:	4,9 mm
Suction:	6,5 mm
Working area:	LBP
Design type:	Hermetic
Model series:	GL
Use with:	Capillary
Power range(HP):	0-2
Power supply:	230 V
Oil type:	ISO VG 22 Ester
Engine type:	RSIR
Article condition:	New
Info:	Oil filled
Shipping weight:	13,00 Kg
Dimensions ( length × width × height ):	23,10 × 16,20 × 18,60 cm
Cooling capacity condition:	T0 -25 C, Tk +55 C
Manufacturer:	ACC Cubigel Huayi Electrolux ZEM
Model:	GL99AA
Stroke volume (cm3):	9,93
Cooling capacity (W):	174
Power (HP):	0,25
Max. Starting current (A):	14,4
Max. Operating current (A):	1,31
Engine type:	RSIR
COP:	0,92
Note:	Static cooling
Conveying and suction volume (m3):	1,72
Oil quantity (l):	0,295
Compressor type:	Piston
Cooling:	Static
RPM:	2900
Power range:	-35 C to -10 C
Alternative:	HLY90AA, NL11F
Pressure line (mm):	4,9
Suction line (mm):	6,5

Type: Hermetic piston compressorsProducer: ACCSeries: HMBP
Model: P12FW
General data

Refrigerant:	R12
Discharge element:	C-V
Cooling:	F
Maximum ambient temperature [ºC]:	43

Compressor’s data

Cylinder capacity [cm³]:	12
Displacement [m³/h]:	2,1
Weight [kg]:	11,5
Oil charge [cm³]:	530
Oil type:	ISO VG 46 MINERAL

Engine’s data

Engine type:	CSIR
Power [KM]:	1/3
Starting element:	HST
Power supply:	220V 50Hz
Voltage range:	198-264
Locked rotor current [A]:	13,8
Running winding resistance (25ºC) [Ω]:	6,88
Starting winding resistance (25ºC) [Ω]:	26,97

Electrical data

Relays:	9660 A 145, MTRP 46
Shielding element:	MRT38AMK, T0168
Starting capacitor volume [μF]:

Connections

	milimeters	inches
Suction/service tube:	8,1
Service/suction tube:	8,2
Discharge tube:	6,5

Compressor ACC Cubigel Huayi Electrolux ZEM GP14FB, LBP – 134a, 220 -240V/1/50Hz, 3/8 HP, discharge 14.17 cm3, motor type CSIR, oil type ISO VG 22 ester, oil charge 400 cm3, 229 W at -25 / +55 °, input power, current 256 W, 1.75 A,expansion device: capillary or valve, fan cooling, weight 11.5 kg , the statutory warranty period shall apply (24 months), Delivery time Info: with “immediately available” and “scarce stock”, usually delivery within 2 days. For “currently not available” delivery time usually 2 weeks or delivery time in urgent cases contact us.

---

Refrigerant:	R134a
Power range(W):	201 – 300 W
Performance range (C):	-35 C to -10 C
Connecting size:	6,5 mm
Suction:	8,1 mm
Working area:	LBP
Design type:	Hermetic
Model series:	GP
Use with:	Expansion/Capillary
Power range(HP):	0-2
Power supply:	230 V
Oil type:	ISO VG 22 Ester
Engine type:	CSIR
Article condition:	New
Info:	Oil filled
Shipping weight:	13,50 Kg
Dimensions ( length × width × height ):	23,10 × 16,20 × 19,60 cm
Cooling capacity condition:	T0 -25 C, Tk +55 C
Manufacturer:	ACC Cubigel Huayi Electrolux ZEM
Model:	GP14FB
Stroke volume (cm3):	14,17
Cooling capacity (W):	228
Power (HP):	0,4
Power consumption (W):	256
Max. Starting current (A):	12
Max. Operating current (A):	1,75
Engine type:	CSIR
COP:	0,9
Note:	Fan cooling necessary
Oil quantity (l):	0,4
Compressor type:	Piston
Kühlung:	Lüfter
Power range:	-35 C to -10 C
Alternative:	NE2130Z
Pressure line (mm):	6,5
Suction line (mm):	8,1

Refrigerant:	R134a
Discharge element:	C-V
Cooling:	F
Maximum ambient temperature [ºC]:	43

Compressor’s data

Cylinder capacity [cm³]:	14
Displacement [m³/h]:	2,4
Weight [kg]:	11,5
Oil charge [cm³]:	400
Oil type:	ISO VG 22 ESTER

Engine’s data

Engine type:	CSIR
Power [KM]:	3/8
Starting element:	HST
Power supply:	220V 50Hz
Voltage range:	198-264
Locked rotor current [A]:	12
Running winding resistance (25ºC) [Ω]:	6,53
Starting winding resistance (25ºC) [Ω]:	23,76

Electrical data

Relays:	9660 A 145, MTRP 46
Shielding element:	MRT40AMK, T0137
Starting capacitor volume [μF]:

Connections

	milimeters	inches
Suction/service tube:	8,1
Service/suction tube:	8,1
Discharge tube:	6,55

Compressor ACC Cubigel Huayi Electrolux ZEM GL99AA, LBP – R134a, 220-240V/1/50Hz, 1/4 HP, discharge 9.93 cm3, motor type RSIR, LRA 14.4A, expansion device: capillary, cooling: static,weight 11 kg , the statutory warranty period shall apply (24 months), Delivery time Info: with “immediately available” and “scarce stock”, usually delivery within 2 days. For “currently not available” delivery time usually 2 weeks or delivery time in urgent cases contact us.

---

Refrigerant:	R134a
Power range(W):	101 – 200 W
Performance range (C):	-35 C to -10 C
Connecting size:	4,9 mm
Suction:	6,5 mm
Working area:	LBP
Design type:	Hermetic
Model series:	GL
Use with:	Capillary
Power range(HP):	0-2
Power supply:	230 V
Oil type:	ISO VG 22 Ester
Engine type:	RSIR
Article condition:	New
Info:	Oil filled
Shipping weight:	13,00 Kg
Dimensions ( length × width × height ):	23,10 × 16,20 × 18,60 cm
Cooling capacity condition:	T0 -25 C, Tk +55 C
Manufacturer:	ACC Cubigel Huayi Electrolux ZEM
Model:	GL99AA
Stroke volume (cm3):	9,93
Cooling capacity (W):	174
Power (HP):	0,25
Max. Starting current (A):	14,4
Max. Operating current (A):	1,31
Engine type:	RSIR
COP:	0,92
Note:	Static cooling
Conveying and suction volume (m3):	1,72
Oil quantity (l):	0,295
Compressor type:	Piston
Cooling:	Static
RPM:	2900
Power range:	-35 C to -10 C
Alternative:	HLY90AA, NL11F
Pressure line (mm):	4,9
Suction line (mm):	6,5

Electrolux, Group, Compressor,Fridge-Freezer, R600a, 1/10HP, S53CY 1PH220V50HZ, LBP, Industrial, Refrigeration

Code Model Nom. Displacem. Expansion Ashrae Cecomaf
hp cc -23,3C° -25C°
kcal/h W
CMP100AC GD24AA 1/20 2,44 C 41 34
CMP101AC GD30AA 1/12 3,08 C 62 52
CMP102AC GD36AA 1/12 3,62 C 72 61
CMP103AC GD40AA 1/10 4,03 C 82 70
CMP104AC AS45AA 1/8 4,56 C/V 112 82
CMP105AC AS60AA 1/6 5,99 C/V 154 114
CMP106AC AS75AA 1/5 6,64 C/V 176 129
CMP107AC AS80AA 1/5 7,39 C/V 198 145
CMP108AC GL45AA 1/8 4,55 C 96 81
CMP109AC GL50AA 1/7 5,12 C 107 91
CMP110AC GL60AA 1/6 5,99 C 126 107
CMP111AC GL70AA 1/5 6,65 C 142 121
CMP112AC GL75AA 1/5 7,39 C 155 132
CMP113AC GL80AA 1/5 8,10 C 170 144
CMP114AC GL90AA 1/5 9,08 C 193 165
CMP115AC GL99AA 1/4 9,93 C 205 175
CMP116AC GP12FB 1/3 12,00 C/V 225 190
CMP117AC GP14FB 3/8 14,00 C/V 270 228
CMP118AC GP16FB 3/8 16,14 C/V 315 266
CMP119AC GP18FB 3/7 18,40 C/V 345 291
CMP120AC GP21FB 2/3 20,72 C/V 415 351
CMP121AC GVY35AA 1/10 3,36 C/V 84 62
CMP122AC GVY40AA 1/9 3,87 C/V 107 79
CMP123AC GVY44AA 1/8 4,38 C/V 122 91
CMP124AC GVY57AA 1/7 5,73 C/V 150 109
CMP125AC GVY66AA 1/5 7,00 C/V 181 132
CMP126AC GVY75AA 1/5 7,52 C/V 205 150
CMP127AC GQY35AA 1/10 3,66 C/V 91 67
CMP128AC GQY40AA 1/9 4,01 C/V 104 76
CMP129AC GQY45AA 1/8 4,56 C/V 121 90
CMP130AC GQY55AA 1/7 5,46 C/V 148 109
CMP131AC GQY60AA 1/6 5,99 C/V 162 119
CMP132AC GQY70AA 1/5 6,64 C/V 179 132
CMP133AC GQY75AA 1/5 7,39 C/V 200 148
CMP134AC GQY80AA 1/5 8,10 C/V 222 165
CMP135AC GQY90AA 1/4 9,05 C/V 251 188
CMP136AC GVM40AA – 3,87 – 107 79
Compressors
Compresseurs
Compresores
Компрессоры Compressori
ELECTROLUX HERMETIC COMPRESSORS – R134a LBP
VOLTAGE 220-240/1/50
Code Model Nom. Displacem. Expansion Ashrae Cecomaf
hp cc -23,3C° -25C°
kcal/h W
CMP137AC GVM57AA – 5,73 – 153 113
CMP138AC GVM66AA – 7,00 – 181 133
CMP139AC GL45AN 1/8 4,55 C 110 93
CMP140AC GL60AN 1/6 5,99 C 153 131
CMP141AC GL70AN 1/5 6,65 C 151 129
CMP142AC GL80AN 1/5 8,10 C 174 148
CMP143AC GL90AN 1/4 9,08 C 191 163

Compressor ACC Cubigel Huayi Electrolux ZEM GP16TG, HMBP – R134a, 200- 220V/220 – 230V/1/50/60Hz, 3/8 HP, discharge 16.15 cm3, motor type CSIR, oil type ISO VG 46 ester, oil charge 400 cm3, 1205 W at +5 / +55 °, input power, current 662 W, 4.28 A, expansion device: capillar or valve, cooling: fan, weight 12.9 kg , the statutory warranty period shall apply (24 months), Delivery time Info: with “immediately available” and “scarce stock”, usually delivery within 2 days. For “currently not available” delivery time usually 2 weeks or delivery time in urgent cases contact us.

Refrigerant:	R134a
Power range(W):	1 – 1,5 kW
Connecting size:	6,5 mm
Suction:	8,1 mm
Working area:	HMBP
Design type:	Hermetic
Model series:	GP
Use with:	Expansion/Capillary
Power range(HP):	0-2
Power supply:	230 V
Oil type:	ISO VG 22 Ester AB46 ISO VG 46 Ester
Engine type:	CSIR
Article condition:	New
Info:	Oil filled
Shipping weight:	24,90 Kg
Dimensions ( length × width × height ):	23,10 × 16,20 × 21,10 cm
Cooling capacity condition:	+5 / +55 C
Manufacturer:	ACC Cubigel Huayi Electrolux ZEM
Model:	GP16TG
Stroke volume (cm3):	16,15
Cooling capacity (W):	1205
Power (HP):	0,4
Power consumption (W):	662
Max. Starting current (A):	23
Max. Operating current (A):	4,28
Engine type:	CSIR
COP:	1,82
Note:	Fan cooling necessary
Oil quantity (l):	0,4
Compressor type:	Piston
Pressure line (mm):	6,5
Suction line (mm):	8,1

www.mbsm.pro ,ZEL ,COMPRESSEUR ,R134a ,1/4 HP ,GVY75AA

Refrigerant:	R134a
Power range(W):	101 – 200 W
Performance range (C):	-35 C to -10 C
Connecting size:	4,9 mm
Suction:	6,5 mm
Working area:	LBP
Design type:	Hermetic
Model series:	GL
Use with:	Capillary
Power range(HP):	0-2
Power supply:	230 V
Oil type:	ISO VG 19 Ester
Engine type:	RSIR RSCR
Article condition:	New
Info:	Oil filled
Shipping weight:	9,60 Kg
Contents:	1,00 Pieces
Dimensions ( length × width × height ):	23,10 × 16,20 × 18,60 cm
Cooling capacity condition:	T0 -25 C, Tk +55 C
Manufacturer:	ACC Cubigel Huayi Electrolux ZEM
Model:	GL80AA
Modelname:	GVY75AA
Stroke volume (cm3):	7,52
Cooling capacity (W):	144
Power (HP):	0,25
Max. Starting current (A):	11,5
Max. Operating current (A):	1,16
Engine type:	RSIR / RSCR
COP:	0,88
Note:	Static cooling
Conveying and suction volume (m3):	1,4
Oil quantity (l):	0,18
Compressor type:	Piston
Power range:	-35 C to -10 C
Alternative:	NEK1116Z , NB1116Z , GL75AA, NL9F
Pressure line (mm):	4,9
Suction line (mm):	6,5

Type: Hermetic piston compressors Producer: ACCSeries: HMBP, cooling
Model: GP12TB
General data



Capillary :	0.42 , 0.32 180 psi	100mm
Refrigerant:	R134a
Discharge element:	C-V
Cooling:	F
Maximum ambient temperature [ºC]:	43

Compressor’s data

Cylinder capacity [cm³]:	12,1
Displacement [m³/h]:	2,1
Weight [kg]:	11,2
Oil charge [cm³]:	350
Oil type:	ISO VG 22 ESTER

Engine’s data

Engine type:	CSIR
Power [KM]:	3/8
Starting element:	HST
Power supply:	220V 50Hz
Voltage range:	187-264
Locked rotor current [A]:	13,5
Running winding resistance (25ºC) [Ω]:	5,75
Starting winding resistance (25ºC) [Ω]:	20,3

Electrical data

Relays:	9660 A 138, MTRP 43
Shielding element:	MRT26AMK, T0181
Starting capacitor volume [μF]:

Connections

Type: Hermetic piston compressorsProducer: ACCSeries: HMBP
Model: GP12TB
General data

Refrigerant:	R134a
Discharge element:	C-V
Cooling:	F
Maximum ambient temperature [ºC]:	43

Compressor’s data

Cylinder capacity [cm³]:	12,1
Displacement [m³/h]:	2,1
Weight [kg]:	11,2
Oil charge [cm³]:	350
Oil type:	ISO VG 22 ESTER

Engine’s data

Engine type:	CSIR
Power [KM]:	3/8
Starting element:	HST
Power supply:	220V 50Hz
Voltage range:	187-264
Locked rotor current [A]:	13,5
Running winding resistance (25ºC) [Ω]:	5,75
Starting winding resistance (25ºC) [Ω]:	20,3

Electrical data

Relays:	9660 A 138, MTRP 43
Shielding element:	MRT26AMK, T0181
Starting capacitor volume [μF]:

Connections

	milimeters	inches
Suction/service tube:	8,1
Service/suction tube:	8,1
Discharge tube:	6,5
